UTRANS-7400CUTRANS-7400C

U-7400C is MPLS-TP based PTN system with 8G capacity that can provide access network configuration and help save CAPEX and OPEX. It can support redundancy of port/line/unit, errorless switching functions, remote initialization for rapid maintenance. With connection-oriented MPLS-TP technology, it can provide OAM, 50 sec switching, and specified H-QoS in various topologies like P to P, Mesh, Ring and Linear, supporting E-LINE, E-LAN, E-TREE services. End to End path provisioning, performance, alarm, operational provisioning, service information are managed by user-friendly EMS.
Network Configuration
System Features

- MPLS-TP based very small-sized PTN with 8G capacity
- Common part redundancy
- Provide FE, GE, E1 CES interfaces
- Support 50ms failover for End-To-End Service
- Support External, Sync-E for network configuration
- Provide differentiated QoS policy by specific service class
- Provide Performance, Alarm and Failure detection Monitoring by Ethernet/MPLS-TP OAM Tool

Main Specifications

Items

Description

Chassis

19” x 1RU x 340mm (W x H x D)

Switching capacity

8G FD per system

Topology

Ring, Linear, Mesh

H/W Redundancy

Power

Clock

External, Loop(Sync-E), Internal, Holdover, Derived

Service

16 E-line, 16 E-lan, 16 E-tree

MPLS-TP

G.8131 Linear, G.8113.1 OAM

QoS

Classification: Port, VID, 802.1p, EXP, Label, 5-tuple
Queuing/Scheduling: 8 priority Qs, SP + WFQ
Metering/Marking: TrTCM, EXP, 802.1p
Shaping/Limiting: Egress Shaping, Ingress limiting
Tunneling Model: Pipe

Circuit Emulation

SAToP, CESoP, CEP, ACR/DCR

L2  functions

802.1Q VLAN, 802.1ad QiQ, 802.1p COS, 802.3ad LACP, Jumbo, Storm Control, Miroring, Port Shutdown, Traffic Monitoring, Auto-nego Mismatch, Loopback, LLCF, Y.1731 OAM,

Management

EMS, CLI, SSH/Telnet, SNMPv2
